F4 OSD Flight Controller 48CH + 40A BLheli - S 4 in 1 Brushless ESC Integrated OSD Module for RC Drone
...See More
PRIVACY PROTECTED
SECURE CHECKOUT
F4 OSD Flight Controller 48CH + 40A BLheli - S 4 in 1 Brushless ESC Integrated OSD Module for RC Drone
Availability:
In Stock
|
FREE Shipping on Orders Over $20
ships worldwide |
$221.92
Flight Controller Specifications:
● Equipped with STM32F405 MCU
● It supports OSD adjustment function and built-in barometer
● Gyroscope: MPU6000
● Firmware: OMNIBUSF4SD
● Built-in betaflight OSD
● Suggest less than 6 LED ( please use BEC module while using more than 6 LED )
● TX control through the furious FPV / tramp peripheral protocol
● Ground station: betaflight
● Built-in VTX module on board
● VTX power: Off / 25 / 200 / 600mW
● Frequency band: 48CH
● Camera voltage: 5V
● Size: 36 x 36mm
● Mounting hole: 30.5 x 30.5mm
● Support DSMX, PPM, SBUS receiver ( setting refers to manual )
ESC Specifications:
● Continuous current: 40A
● Peak current: 45A ( 5S )
● Input voltage: 2 - 4S LiPo
● Size: 39 x 41mm ( include pad )
● Mounting hole: 30.5 x 30.5mm ( M3 )
● Integrated PDB
● Integrated FC power
● Integrated battery monitoring
● Support Oneshot42, Oneshot125, DShot150, DShot300 and DShot600
● Equipped with STM32F405 MCU
● It supports OSD adjustment function and built-in barometer
● Gyroscope: MPU6000
● Firmware: OMNIBUSF4SD
● Built-in betaflight OSD
● Suggest less than 6 LED ( please use BEC module while using more than 6 LED )
● TX control through the furious FPV / tramp peripheral protocol
● Ground station: betaflight
● Built-in VTX module on board
● VTX power: Off / 25 / 200 / 600mW
● Frequency band: 48CH
● Camera voltage: 5V
● Size: 36 x 36mm
● Mounting hole: 30.5 x 30.5mm
● Support DSMX, PPM, SBUS receiver ( setting refers to manual )
ESC Specifications:
● Continuous current: 40A
● Peak current: 45A ( 5S )
● Input voltage: 2 - 4S LiPo
● Size: 39 x 41mm ( include pad )
● Mounting hole: 30.5 x 30.5mm ( M3 )
● Integrated PDB
● Integrated FC power
● Integrated battery monitoring
● Support Oneshot42, Oneshot125, DShot150, DShot300 and DShot600
Type: ESC,Flight Controller
Package weight: 0.095 kg
Package size (L x W x H): 6.00 x 6.00 x 3.00 cm / 2.36 x 2.36 x 1.18 inches
Package size (L x W x H): 6.00 x 6.00 x 3.00 cm / 2.36 x 2.36 x 1.18 inches
Package Contents: 1 x Flight Controller, 1 x ESC, 3 x Cable, 1 x MMCX to SMA Antenna Cable
