Main Features: - Highly integrated one board, to solve the Ramps1.4 combination interface cumbersome problem. - Optimized layout routing and thermal design, the whole board performance is more stable. - Large USB, more stable connection, more concise interface, wiring more convenient, more stable, longer life. - On-board 4-channel A4988 16-step stepping motor driver ( Z-Axis motor interface ). - PWM DC 3 outputs ( 1 channel high current, 3 channel medium current, 2 channel small current ). - Mos tube with high performance and low on-resistance is used for driving, and the heat dissipation is better. - ST original power supply chip, support 12V - 24V power input to solve the Ramps voltage conversion chip fever problem. - Can accept 24V input, the same system power can be reduced to 1/4 of the hot bed current, solve the hot-bed MOS tube heating problem effectively. - Can use open source firmware Marlin, configuration and Ramps1.4 exactly the same, can directly replace Ramps1.4. - Can be directly connected Ramps1.4, 2004LCD control panel and 12864LCD control panel ( remove the L-type adapter plate ).
Note: packages might include random colors, but has no influence to its operation.
Brand: Anet Model Number: V1.0
Package weight: 0.093 kg Product Size(L x W x H): 10.00 x 9.50 x 2.00 cm / 3.94 x 3.74 x 0.79 inches Package Size(L x W x H): 16.00 x 10.50 x 3.00 cm / 6.3 x 4.13 x 1.18 inches
Package Contents: 1 x Anet V1.0 3D Printer Controller Board
